PAC PAM Chlorine Dosing Pump for Water Treatment & Chemical Feed

Date 16/01/2025

Company Profile

1. Dosaki pump is manufacturer of metering pump. diaphragm pump and dosing equipment.
2. Professional technicians and rich industry experience, located in Shanghai city.
3. Dosaki foccus on one-stop industrial pump system solution and service.

Pump’s Features

Full closed drive end：

1. The top of drive end with bearing and cover plate.
2. Higher concentricity, enhance output efficiency and drive efficiency.
3. Prevent the dirt into drive end, make the operation more stable and efficiency
4. Benefit to pump (without motor) delivery.


Casting and precision machining：

1. Precision casting, smooth surface and no sand hole.
2. CNC machining with high precision and concentricity.
3. EPOXY coating, strong and durable.
4. Structural reinforcement design, firm and durable.
5. The connecting bolts are made of stainless steel.


Eccentric drive mechanism：

1. Adopt forging process and precision machining, strong and durable.
2. Quenching and tempering treatment, wear-resistant and long life time.
3. Shaped structure coupling, fewer parts, high reliability and not easy to wear.
4. Precision machining, better concentricity and balance.


Worm gear and worm：

1. worm gear be bronze, wear-resistant and low noise.
2. Worm be alloy steel and tempered, high strength and wear resistance.
3. Adopt precision machining, good linearity and high gear meshing.
4. Two bearing support design, stable and high concentricity.


Double diaphragm chamber design：

1. Double diaphragm design, fluid chamber independent from the drive end.
2. Main diaphragm be multi-layer design, with high toughness PTFE surface.
3. Auxiliary diaphragm be Teflon, static sealing.
4. Once main diaphragm broken, Auxiliary diaphragm also can prevent the medium into drive end.


High strength diaphragm：

1. Multi-layer composite material.
2. The surface layer be high-toughness PTFE, support by an iron core, back layer be rubber reinforced with nylon fabric.
3. The whole diaphragm durable and stable.

High precision valve ball：

1. Ceramic or stainless steel.
2. Ceramic ball is made of yttrium stabilized zirconia material with high strength and wear resistance.
3. High roundness and good sealing performance.

Performance Data

Model
50HZ
60HZ
Diaphragm size(mm)
Motor(w)
Flow(LPH)
Pre(bar)
rpm
Flow(LPH)
Pre(bar)
rpm
KS15/1.0
15
10
100
18
10
120
65
40/60
KS25/1.0
25
10
100
30
10
120
65
40/60
KS40/0.7
40
7
150
48
7
180
65
40/60
KS60/0.6
60
6
100
72
6
120
84
60
KS80/0.5
80
5
100
96
5
120
84
60
KS100/0.4
100
4
150
120
4
180
84
60
KS130/0.4
130
4
150
156
4
180
84
60
KS150/0.5
150
4
150
180
4
180
84
60



Model
50HZ
60HZ
Diaphragm size(mm)
Motor(Kw)
Flow(LPH)
Pre(bar)
rpm
Flow(LPH)
Pre(bar)
rpm
KM10/1.2
10
12
48
12
12
58
60
0.25/0.37
KM25/1.0
25
10
48
30
10
58
60
0.25/0.37
KM50/1.0
50
10
96
60
10
115
60
0.25/0.37
KM90/0.7
90
7
48
108
7
58
112
0.37
KM120/0.7
120
7
48
144
7
58
112
0.37
KM170/0.7
170
7
96
204
7
115
112
0.37
KM240/0.7
240
7
96
288
7
115
112
0.37
KM330/0.5
330
5
144
396
5
173
112
0.37
KM400/0.5
400
5
144
480
5
173
112
0.55
KM500/0.5
500
5
144
600
5
173
112
0.55



Model
50HZ
60HZ
Diaphragm size(mm)
Motor(Kw)
Flow(LPH)
Pre(bar)
rpm
Flow(LPH)
Pre(bar)
rpm
KB240/1.0
240
10
48
288
10
58
150
0.75
KB320/1.0
320
10
48
384
10
58
150
0.75
KB500/1.0
500
10
96
600
10
115
150
0.75
KB680/0.7
680
7
96
816
7
115
150
0.75
KB760/0.5
760
5
144
912
5
173
150
0.75
KB1000/0.4
1000
4
144
1200
4
173
150
0.75
KB1200/0.4
1200
4
96
1440
4
115
185
1.1
KB1600/0.3
1600
3
144
1920
3
173
185
1.1
KB1800/0.3
1800
3
144
2160
3
173
185
1.1
